Name: Hybrid bond CNC diamond wheel for high-performance flute grinding
Brand: ZHENGZHOU SHINE ABRASIVES CO.,LTD
SKU: 4V2 1A1 14A2 1v1
Price: 50.00 USD
Availability: InStock

Rumah Produk Mesin penggiling CNC

Hybrid bond CNC diamond wheel for high-performance flute grinding

Detail produk:

Tempat asal:	CINA
Nama merek:	Shine Abrasives
Sertifikasi:	ISO
Nomor model:	4V2 1A1 14A2 1v1

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	2 pcs
Harga:	FOB
Kemasan rincian:	satu dalam kotak kertas
Waktu pengiriman:	5 hari kerja
Syarat-syarat pembayaran:	L/c, t/t
Menyediakan kemampuan:	1000 PCS dalam satu minggu

Kontak

Detil Deskripsi produk

Aplikasi:	Mesin CNC	Kecepatan:	6000rpm
Warna:	Perak	Tekanan maksimal:	5mpa
Ukuran:	6 inci	Ukuran punjung:	7/8 inci
Suhu maksimal:	150 ℃	Diamond Rim Ukuran:	6x6mm
Jenis Obligasi:	Hibrida	Menjalin kedekatan:	Damar
Kode HS:	6804211000	Efisiensi:	CEPAT
Kecepatan Max:	100m/s	Max Rpm:	6000rpm
Kekerasan:	Tinggi
Menyoroti:	Hybrid bond CNC diamond wheel , CNC flute grinding wheel , high-performance diamond grinding wheel

Hybrid bond CNC diamond wheel for high-performance flute grinding

Hybrid bond CNC diamond wheel for high-performance flute grinding.Hybrid bond is Resin Bond, Metal Bond, and or processing methods to create a Hybrid that encompasses enhanced properties to deliver high performance results for some of manufacturing’s toughest grinding applications.

Wheel sizes form:

Diameter of D	Diamond depth of U	R	X	H
50mm	2,3,4,5,6,7,8,9,10	1/2 U	3 or 5 or 6	12.7,20,25.4 32 customize
75mm	2,3,4,5,6,7,8,9,10	1/2 U	3 or 5 or 6	12.7,20,25.4 32 customize
100mm	2,3,4,5,6,7,8,9,10	1/2 U	3 or 5 or 6	12.7,20,25.4 32 customize
125mm	2,3,4,5,6,7,8,9,10	1/2 U	3 or 5 or 6	12.7,20,25.4 32 customize
150mm	2,3,4,5,6,7,8,9,10	1/2 U	3 or 5 or 6 or 10	12.7,20,25.4 32 customize
175mm	2,3,4,5,6,7,8,9,10	1/2 U	3 or 5 or 6 or 10	12.7,20,25.4 32 customize
200mm	2,3,4,5,6,7,8,9,10	1/2 U	3 or 5 or 6 or 10	12.7,20,25.4 32 customize

Others sizes are available per requested.

*Grinding, PCD, PCBN, CVD, MCD, hard alloy and other cutting tools

*Bonding agents: ceramic bonding agents, resin bonding agents, metal bonding agents

*The particle size can reach up to 10000#

*Cutting edge quality less than 5 microns

*Provide dressing wheels to trim PCD grinding wheels
*Precision grinding: capable of achieving high accuracy and surface finish
*The bowl is mainly used for tool sharpening and surface milling, suitable for grinding metal and non-metal hard and brittle material with low iron content.
